TripSaver® II Cutout-Mounted Recloser
Minimize outages with lateral automation designed for maximum value.
Up to 80% of faults on overhead lateral lines are caused by storm debris, vegetation, and animals.
S&C's TripSaver II single-phase recloser makes integrating automation easy. It replaces fuses to restore power automatically for temporary faults and isolate permanent faults to minimize impact and accelerate restoration.
Avoid outages and unnecessary truck rolls with the the field-proven recloser that delivers fast improvements.
Why Choose the TripSaver II Recloser Over Conventional Fuses?
Lateral fusing strategies force trade-offs. Either every fault results in a sustained outage and a truck roll, or every customer on the feeder experiences a momentary outage. See how S&C’s single-phase recloser combines the best of fuse-saving and fuse-blowing strategies in one device to mitigate outages closer to the fault.
Why Utilities Have Upgraded to S&C’s Single-Phase Recloser
You can achieve multiple goals at once by advancing your lateral protection strategy with TripSaver II reclosers.
Avoids Outages
Mitigate momentary and sustained outages despite the weather to improve SAIDI, SAIFI, and MAIFI metrics.
O&M Cost Savings
Avoid unnecessary truck rolls to allow crews to focus on value-add modernization initiatives and restoration.
Rapid Installation and Results
Easily integrate devices into your system using S&C cutouts and programmable fuse curves.
Eco-Friendly Benefits
Lower your carbon footprint with fewer trips, and replace dated technology that can have environmental risks.
Capture 24/7 Data and Analytics
Get greater grid visibility and data-driven results by adding Gridware® GridscopeTM solar-powered sensing and monitoring to your TripSaver II reclosers.
- Monitor faults and device response
- Respond to events more efficiently
- Measure ROI with data from a secure dashboard
- Easily add communications to deployments
How the TripSaver Recloser Has Helped Utilities
See how utilities around the world have reduced outage minutes and improved operational savings with TripSaver reclosers.
TripSaver II Recloser Construction and Design
Explore key components using the 3D product viewer below. For instructions, click the Help button.
Features that Help Improve Fault Response and Operations
Interrupting Ratings
Offers 6.3 kA and 4.0 kA fault-interrupting at 15.5 kV and 29 kV.
TCC Curve Variety
Hundreds of TCC curves available for easy integration and device coordination
Vacuum Interrupter
Fault current quietly contained and interrupted inside a vacuum-sealed chamber.
Local Manual Open
Breaks the load without a loadbreaking tool.
Non-Reclosing Modes
Disables the programmed automatic reclosing, with three curves available.
Delayed-Close Option
Use cordless power module to add a time delay for crews before the vacuum interrupter closes*.
Operational Status
LCD screens display real-time device status with information scrolling.
Ice Breaking
Capability for the recloser to break through approximately ¾-inch (20mm) of ice.
Sectionalizing Mode
Can operate as a sectionalizer over a range of fault currents
Restraint Feature
In-rush restraint feature always on; will not nuisance trip on in-rush.
Communications Gateway
Adds functionality for gang operation and remote drop open.
Sequence Coordination
Improves coordination between upstream and downstream reclosers to prevent nuisance momentary outages
*Requires firmware v.2.1 or later
See How Single-Phase Reclosers Can Work for You
Discover their benefits and get expert tips on small to large-scale deployments based on experiences with utilities like yours.
Need Support?
S&C is here to help you through any stage in your grid-modernization journey, from system studies to installation videos. Explore more below.
Product Details
(On mobile, swipe left for remaining ratings information.)
| 50/60-Hz Ratings① | With Porcelain Insulator | With Polymer Insulator | |||||||
|---|---|---|---|---|---|---|---|---|---|
| kV | Amperes, RMS② | Leakage Distance to Ground Minimum, Inches (mm) | Base Catalog Number | Leakage Distance to Ground Minimum, Inches (mm) | Base Catalog Number | ||||
| System Class | Nom. | Max | BIL | Cont. | Interr., Sym | ||||
| 15 | 15 | 15.5 | 110 | 40 | 4 000 | 8½ (216) | 990511 | 14¾ (375) | 990511-P |
| 6 300 | 8½ (216) | 990611 | 14¾ (375) | 990611-P | |||||
| 100 | 4 000 | 8½ (216) | 990111 | 14¾ (375) | 990111-P | ||||
| 6 300 | 8½ (216) | 990211 | 14¾ (375) | 990211-P | |||||
| 200 | 4 000 | 8½ (216) | 990311 | 14¾ (375) | 990311-P | ||||
| 6 300 | 8½ (216) | 990411 | 14¾ (375) | 990411-P | |||||
| 25 | 25 | 29 | 125 | 40 | 4 000 | 11 (279) | 990522 | — | — |
| 6 300 | 11 (279) | 990622 | — | — | |||||
| 150 | 4 000 | 17 (432) | 990532⬤ | 26½ (673) | 990532-P⬤ | ||||
| 6 300 | 17 (432) | 990632⬤ | 26½ (673) | 990632-P⬤ | |||||
| 125 | 100 | 4 000 | 11 (279) | 990122 | — | — | |||
| 6 300 | 11 (279) | 990222 | — | — | |||||
| 150 | 100 | 4 000 | 17 (432) | 990132⬤ | 26½ (673) | 990132-P⬤ | |||
| 6 300 | 17 (432) | 990232⬤ | 26½ (673) | 990232-P⬤ | |||||
| 125 | 200 | 4 000 | 11 (279) | 990322 | — | — | |||
| 6 300 | 11 (279) | 990422 | — | — | |||||
| 150 | 200 | 4 000 | 17 (432) | 990332⬤ | 26½ (673) | 990332-P⬤ | |||
| 6 300 | 17 (432) | 990432⬤ | 26½ (673) | 990432-P⬤ | |||||
① For 50-Hz applications, specify Microprocessor Control for Application on 50-Hz systems, catalog number suffic "-F".
② Minimum trip current is 5 amperes for 40 A continuous, 5 amperes for 100 A continuous and 10 amperes for 200 A continuous TripSaver II reclosers.
⬤ Applicable for protection of single-phase-to-neutral circuits only in solidly-grounded-neutral (multi-grounded-neutral) 34.5-kV systems where leakage distance to ground meets user's requirement. Uses 25-kV, 150-kV BIL mounting.
